Ares

R9202421-7/R9202421-8

7000 lumens and 8000 lumens, Tri-LCD 4K, laser

Specification:

Panel TechnologyPerfect image quality with 3LCD Tech

Panel Resolution4K, 3840*2160 Resolution

Dynamic Contrast Ratio5,000,000:1

Keystone Correction160° Vertical, ±29° Horizontal. Pncusion/Barrel Correction 6 Corner Geometry correction, Multi-point correction

Unit Size (W x H x D)405 x 358 x 137mm

Model
Ares 7K & 8K

Part number
7000 lumens: Model no: R9202421-7
8000 lumens: Model no: R9202421-8

Basic Parameter:

Display Technology
3LCD

Resolution
4K,3840*2160 resolution

Contrast
5,000,000:1

Throw Ratio
1.08-1.76:1

Projection Method
Front, Rear, Ceiling, Table Top;

Projection Image support
Horizontal and vertical flip

Displayable Colours
1.07 Billion

Projection Distance
1.025-25.48m (Standard Power Lens)

Projection Screen Size
100″ at 2.94m

Others :

Lamp Type/Lamp Life
350W Roller type laser light source,
20000-40000 hrs life.

Keystone Correction
160° Vertical,±29° Horizontal. Pincushion/Barrel
Correction 6 Corner Geometry correction,
Multi-point correction.

Dimensions (W x D x H)
405*358*137mm

Net Weight
8kg

Power Supply
100-240V, 50-60Hz

Power Consumption
Power Consumption: 600W

Operating Conditions
-10°C~ 50°C temperature

Max. Humidity & Altitude
85% & 3000m

Fan Noise
As low as 29 dBa

I/O CONNECTOR :

Input
HDMI x2 USB-A*1; USB-B*1

Control
RS232/RJ45
